Diaphragm valve material app temperature bound
|
Material |
Medium temperature |
Material |
Medium temperature |
|
FRPP |
-20℃~ +90℃ |
PVDF |
-40℃~ +120℃ |
|
UPVC |
-40℃ ~ +60℃ |
CPVC |
-40℃ ~ +95℃ |
Part material list
|
No. |
Name |
Material |
No. |
Name |
Material |
NO. |
Name |
Material |
|
1 |
Stud |
Steel, Stainless Steel |
8 |
YokeNut |
HT300 Steel |
15 |
Flim |
EPDM.IIR |
|
2 |
Indicator |
Steel |
9 |
Stem |
Steel, Stainless Steel |
16 |
Diaphragm |
F46.PFA. PVDF.PTFE |
|
3 |
Stopcover |
PC.AS |
10 |
Bonnet |
FRPP,PVDF UPVC,CPVC |
17 |
Pin |
Steel, Stainless Steel |
|
4 |
Washer |
Steel, Stainless Steel |
11 |
Flat bearing |
Ball beraing |
18 |
Disc |
Steel, Stainless C.I.FRP |
|
5 |
Wheel |
ABS |
12 |
Nut |
Steel, Stainless Steel |
19 |
Diaphragm |
F46 |
|
6 |
RetainingNut |
FRPP Steel, Stainless Steel |
13 |
Stud |
Sted, Stainless Steel |
|||
|
7 |
Liningring |
PP |
14 |
Body |
FRPP, PVDF UPVC, CPVC |
